상품 설명
- 고급 코어 적용으로 효율 향상
- 에폭시 레진 진공가압 함침 절연 시스템
- Anti-Tracking 바니쉬 적용에 따른 내환경성, 내화학성, 내구성 증대
- 다양한 외형치수 만족(KS, IEC, NEMA, EN, JIS, API, BSI, AS, IS)
- Heavy Duty에도 적합한 베어링 구조
- FEM 해석에 따른 최적의 구조
| TYPE | 규격명 | S/N |
| HLB5 310-45E | 185KW 4P 3300V B3 | 20140034-RMH-003 |
| HLB5 310-66E | 110KW 6P 6600V 60HZ B3 | 20144134-RMH-D19 |
| HLB5 312-85V | 132KW 8P 3300V V1 | 20120847-RMH-246 |
| HLB5 312-85V | 132KW 8P TE 3300V V1 | 20124379-RMH-C82 |
| HLB5 312-85V | 132KW 8P 3300V V10 | 20111587-RMH417 |
| HLB5 314-65E | 150KW 6P 3300V B3 | 20121739-RMH-514 |
| HLB5 314-85V | 132KW 8P 3300V V1 | 20132026-RMH-762 |
| HLB5 316-66E | 150KW 6P TE 6600V B3 | 20120974-RMH-311 |
| HLB5 318-15V | 90KW 10P 3300V V1 | 20132026-RMH-763 |
| HLB5 318-25E | 150KW 2P 3300V B3 | 20132026-RMH-765 |
| HLB5 318-25E | 150KW 2P 3300V B3 | 20142983-RMH-957 |
| HLB5 318-68E | 160KW 6P 6000V 50HZ B3 | 20121228-RMH-383 |
| HLB5 350-15V | 132KW 10P 3300V V1 | 20120847-RMH-253 |
| HLB5 350-15V | 132KW 10P 3300V V1 | 20120847-RMH-247 |
| HLB5 350-15V | 132KW 10P TE 3300V V1 | 20110248-RMH-057 |
| HLB5 352-15V | 150KW 10P 3300V V1 | 20120847-RMH-248 |
| HLB5 352-65E | 250KW 6P TE 3300V B3 | 20112473-RMH-655 |
| HLB5 352-68E | 220KW 6P 6000V 50HZ B3 | 20121228-RMH-384 |
| HLB5 352-85X | 190KW 8P TE 3300V V5 | 20120545-RMH-151 |
| HLB5 352-86E | 190KW 8P 6600V B3 | 20111061-RMH-298 |
| HLB5 352-86V | 190KW 8P TE 6600V B3 | 20101391-RMH-890 |
| HLB5 354-66E | 300KW 6P TE 6600V B3 | 20101142-RMH-296 |
| HLB5 354-85E | 250KW 8P 3300V B3 | 20110986-RMH-280 |
| HLB5 354-85E | 250KW 8P 3300V B3 | 20132660-RMH-947 |
| HLB5 402-65E | 375KW 6P TE 3300V B3 | 20132513-RMH-902 |
| HLB5 402-66E | 350KW 6P 6600V B3 | 20104531-RMH-B96 |
| HLB5 402-66E | 355KW 6P 6600V 60HZ B3 | 20144134-RMH-D18 |
| HLB5 452-65E | 600KW 6P 3300V B3 | 20112954-RMH-802 |
| HLB5 452-88E | 400KW 8P TE 6300V B3 50HZ | 20102031-RMH-530 |
| HLB5 454-15V | 375KW 10P 3300V V10 | 20102324-RMH-574 |
| HLB5 454-15V | 375KW 10P 3300V V10 | 20111993-RMH-524 |
| HLB5 454-15V | 375KW 10P 3300V V1 | 20125403-RMH-G57 |
| HLB5 454-15V | 375KW 10P TE 3300V V10 | 20104785-RMH-C96 |
| HLB5 454-15V | 375KW 10P TE 3300V V10 | 20110792-RMH-219 |
| HLB5 454-46E | 680KW 4P TE 6600V B3 | 20120974-RMH-309 |
| HLB5 454-65E | 550KW 6P TE 3300V B3 | 20132513-RMH-901 |
| HLB5 454-65E | 710KW 6P TE 3300V B3 60HZ | 20123726-RMH-A39 |
